LinkSprinter®

Pocket Network Tester

A 10-second, simple network connectivity test on copper Ethernet links; Ideal for frontline/helpdesk staff.

Overview

The LinkSprinter Pocket Network Tester verifies the functionality of copper Ethernet links and identifies errors in less than 10 seconds. The tester reveals network connectivity status and port information while ensuring documentation for every link. The comprehensive AutoTester measures PoE voltage, performs a switch test, and confirms the DHCP server is running and responsive. The tester also verifies gateway/router, internal IP service, and cloud reachability. When paired with the secure Link-Live Cloud Service, the Network Tester automatically uploads results and allows annotation of results enabling job supervisors to easily manage the progress of deployment and troubleshooting tasks assigned to their team.

Key Features

  • Discover the nearest switch name and port information via CDP/LLDP/EDP, and verify link speed/duplex and connectivity to TCP/IP networks.
  • Validate Power-over-Ethernet (PoE) voltage from power sourcing equipment (PSE) according to 802.3af/at standards.



  • View detailed test results, add comments, and run cable tests using your mobile device over a Wi-Fi hotspot built into the LinkSprinter.
  • Automate reporting and enable collaboration with test results upload and management via the free Link-Live Cloud Service.
Capabilities

Mobile Device



Pair your LinkSprinter with your mobile device to discover detailed information on:
– Port name
– Nearest switch name, port #, and link speed
– PoE voltage
– DHCP server, DNS server, and gateway address
– Model
– Server addresses


Models & Accessories
Model Description
LSPRNTR-300 Includes: (1) LinkSprinter and wrist strap
LSPRNTR-300-5PK LinkSprinter Model 300 – 5PK
LSPRNTR-300-10PK LinkSprinter Model 300 – 10PK
LSPRNTR-HOLSTER LinkSprinter Holster with Test Cord
LINKSOLUTIONS-KIT Includes: (1) LinkRunner AT – 2000 and (2) LinkSprinters
LR-G2-LS-KIT Includes: (1) LinkRunner G2 with Li-ION battery, power supply with regional power plugs, Wireview wire mapper #1, Inline RJ-45 coupler, USB 2.0 to Micro USB cable, 8G Micro SD card, small soft case, coupler, Quick Start guides, (2) LinkSprinters, and (2) LinkSprinter holsters.
LR-G2-LS-KIT-1YS 1 year AllyCare Support for LR-G2-LS-KIT
LR-G2-LS-KIT-3YS 3 year AllyCare Support for LR-G2-LC-KIT
Specifications
General
Dimensions 4.36 in x 1.6 in x 1.28 in (11.07 cm x 4.06 cm x 3.25 cm)
Weight with batteries Model 300: 0.255 lb (0.116 kg)
Cable length measurement Measurable cable lengths are from 3 ft (1 m) to 656 ft (200 m)
Environmental
Operating Temperature and Relative Humidity 32°F to 122°F (0°C to 50°C ), Relative Humidity 5% to 90% Non-condensing
Storage Temperature  -4°F to 140°F (-20°C to 60°C)
Shock and Vibration Random 2g, 5 Hz – 500 Hz (class 2), 1 m drop
Safety CAN/CSA-C22.2 No. 61010-1-12, UL Std. No. 61010-1 (3rd Edition), IEC61010-1:2010, Pollution degree 2
Altitude Operating: 13,123 ft  (4,000 m) Storage: 39,370 ft (12,000 m)
EMC EN 61326-1:2006
Certifications and Compliance Conforms to relevant European Union directives
Conforms to relevant Australian standards
Listed by the Canadian Standards Association
Conforms to relevant FCC standards
Wi-Fi Hot Spot
Specification Compliance IEEE 802.11b/g
Frequency Channels 802.11 Channels 1 thru 11 (Default is 11)
Operating Frequency 2.412 ~ 2.484 GHz, ISM Band
Regulatory Domain EN 301 489-1/17
Browser Internet Explorer 9.0, Firefox 3.6, Chrome 5.0, Safari 5.1 (minimum revision)
